| उत्पत्ति के प्लेस: | चीन |
|---|---|
| ब्रांड नाम: | TMTeck |
| मॉडल संख्या: | टीएस27/आई3 |
| न्यूनतम आदेश मात्रा: | 1 |
| मूल्य: | बातचीत योग्य |
| पैकेजिंग विवरण: | दफ़्ती |
| प्रसव के समय: | 4-6 कार्य दिवस |
| भुगतान शर्तें: | टी/टी, वेस्टर्न यूनियन, पेपैल |
| आपूर्ति की क्षमता: | 100 पीसी / एक सप्ताह |
| मॉडल संख्या: | 5L128-0.75x10-TS27/5L128-96x10-I3 | तत्व: | 128 |
|---|---|---|---|
| तत्व आकार: | लाइनर | आकार: | LxWxH 102x21x35(मिमी) 4.01x0.83x1.38(इंच) |
| रंग: | चाँदी | ||
| प्रमुखता देना: | TS27 I3 immersion ultrasonic probe,immersion probe for ultrasonic testing,TS27 I3 waterproof transducer |
||
Immersion Probe: It can be used together with water wedges, or the test samples can be placed in water to complete the test.
Advantages
1. Acoustic impedance matched to water, suitable for work piece inspection of geometrically complex shapes.
2. Designed to fit onto the wedge, easy to couple to a variety of surfaces with adjustable underwater sound paths.
3.Single linear scan can cover distances from 30 mm to 90 mm.
4.High accuracy , can work normally for 24 hours under one meter of water depth.
Applications
1.Testing of sheets or fittings made of steel, aluminum or other materials.
2.The composite was tested to detect defects such as delamination and disbonding.
3.Large area scanning of the detected object, online thickness measurement.
Specification
| Probe Series |
Model |
Compatible Model |
Element Shape |
Freq (MHz) | E-Nos | Pitch (mm) |
Active (mm) |
Elev.(mm) | Size(LxWxH) |
| TS27/I3 | 1L64-1.5x12 | 1L64-96x12 | Linear | 1 | 64 | 1.50 | 96.0 | 12.0 |
102x21x35 (mm) (in) |
| 2.25L128-0.75x12 | 2.25L128-96x12 | Linear | 2.25 | 128 | 0.75 | 96.0 | 12.0 | ||
| 3.5L128-0.75x10 | 3.5L128-96x10 | Linear | 3.5 | 128 | 0.75 | 96.0 | 10.0 | ||
| 5L128-0.75x10 | 5L128-96x10 | Linear | 5 | 128 | 0.75 | 96.0 | 10.0 | ||
| 7.5L128-0.75x10 | 7.5L128-96x10 | Linear | 7.5 | 128 | 0.75 | 96.0 | 10.0 |
*The standard cable length is 2.5m/8.2ft. The phased probe can be customized,include frequency, element number and pitch,etc.
Quick Details
Model Number:5L128-0.75x10-TS27/5L128-96x10-I3
Element:128
Element Shape:linear
Size:LxWxH 102x21x35(mm) 4.01x0.83x1.38(in)
Application:Testing of sheets or fittings made of steel
Warranty:12 Months
Case:Stainless steel
Customization:yes
Type:phased array probe
Color:Silver
MOQ:1
